Tuesday, November 29, 2011

Answer for Chemistry P1 2011

Answer for P1:

1 B 26 B
2 B 27 C
3 D 28 A
4 A 29 A
5 D 30 C
6 C 31 C
7 B 32 C
8 A 33 B
9 D 34 C
10 A 35 D
11 C 36 B
12 C 37 C
13 D 38 D
14 A 39 C
15 D 40 B
16 D 41 C
17 D 42 B
18 C 43 C
19 B 44 D
20 B 45 C
21 A 46 D
22 B 47 C
23 B 48 C
24 A 49 D
25 A 50 B

Thursday, October 27, 2011

Answer Scheme for Form 4 Chemistry (Akhir Tahun 2011)

Answer Scheme for Form 4 Chemistry (Akhir Tahun 2011)

Answer

Tuesday, August 16, 2011

Form 4 Revision

Chapter 2 Structure of Atom

1        Table 1 shows the incomplete information about 3 atoms; X, Y and Z.
Atom
Proton number
Number of neutron
Number of electron
X

8
6
Y
6
6

Z
17

17

                                                                  Table 1
(a)                    State the name of subatomic particles that are found in nucleus of an atom.

……………………………………………………………………………………………  [1 mark]

(b)                    (i)         What is the term of the total number of protons and neutrons in an atom?

            …………………………………………………………………………………… [1 mark]

(ii)               The total number of protons and neutrons for atom Z is 35.
What is the number of neutron in atom Z?

……………………………………………………………………………………  [1 mark]

(iii)       Write the symbol for atom Z in the form of    A   X.
                                                                                                                                             Z
……………………………………………………………………………………  [1 mark]

(iv)       Draw the atomic structure of atom Z.





                                                                                                                                    [1 mark]

(c)                    Atom X and atom Y are isotopes of an element.
(i)                 What is the proton number of atom X?

……………………………………………………………………………………  [1 mark]

(ii)               Write the electron arrangement of atom Y.

……………………………………………………………………………………  [1 mark]

(iii)             What is valence electron of atom X?

……………………………………………………………………………………  [1 mark]

(iv)             Why atom X and atom Y has same chemical properties?

…………………………………………………………………………………… [1 mark]

(v)               State one use of the isotope X in archaeology field.

…………………………………………………………………………………… [1 mark]
2          Diagram 2 shows the chemical symbols which represent three elements X, Y and Z
            The letters used are not the actual symbols of the elements.

  9
     X
  4

32
     Y
15

31
     Z
15
                                                                    Diagram 2

(a)          (i)     What is meant by proton number?

                         ……………………………………………………………………………………     [1 mark]

                        (ii)     State the proton number for atom X

                      ……………………………………………………………………………………… [1 mark]

(b)   What is represented by the number 32 for the element  Y?

……….……………………………………………………………………………………  [1 mark]

(c)          (i)    Atom Y and Z are isotopes. State the difference between the two atoms.

                   ..……………………………………………………………………………………… [1 mark]

                         (ii)   State one use of isotopes in daily life.

                    ……………….………………………………………………………………………  [1 mark]

(d)           (i)    Write the electron arrangement of atom Y.

                                  ………………………………………………………………………………………  [1 mark]

                          (ii)  Determine the number of valence electron for atom Y.

                     ………………………………………………………………………………………  [1 mark]

                     (ii)  Draw the electron arrangement for atom Z.






[2 marks]

3          Diagram 3.1 shows the arrangement of particles of substance X at different temperatures.









(a)                What is the physical state of substance X at
                        (i)         60 oC   : .........................................................................

                        (ii)        90 oC   : .........................................................................                                         [2 marks]

            (b)        State the movement of particles of substance X at 60 oC.

                        ....………………………………………………………………………………………    [1 mark]

            (c)        Graph 3.2 shows the graph of temperature against time when substance X is heated                                      from 60 oC to 90 oC.












                        (i)         What is meant by melting point?
                                                             ……………………………………………………………………………………………..
                                                ……………………………………………………………………………………[1 mark]

                        (ii)        Based on Graph 3.2, state the melting point of substance X.
                         …………………………………………………………………………………… [1 mark]

                        (iii)       Explain why the temperature remains constant from t1 to t2.

                                    ...................................................................................................................................

                                    ................................................................................................................................[2 marks]

            (d)        (i)         Substance X cannot conduct electricity in any state.
                                    State the type of particles of substance X.

                                    ..................................................................................................................................[1 mark]
                        (ii)        Table 3.3 shows two substances.

Magnesium oxide

Carbon dioxide


Table 3.3



                                    Which substance has the same type of particles as substance X?
                                    Tick (√ ) the correct answer.
[1 mark]

Wednesday, May 18, 2011

Form 5 Chapter 4 Thermochemistry

Describe an experiment to determine the heat of precipitation of silver chloride


Diagram:






Apparatus:
Measuring cylinders, thermometer and plastic cup

Materials:
0.5 mol dm-3 silver nitrate solution, 0.5 mol dm-3 sodium chloride solution


Procedure:
1.      25cm3 of 0.5 mol dm-3 sodium chloride solution is measured and poured into a clean and dry plastic cup using a measuring cylinder.
2.      The initial temperature of sodium chloride solution is measured and then recorded.
3.      Using another measuring cylinder, 25 cm3 of 0.5 mol dm-3 silver nitrate solution is measured. The initial temperature of the silver nitrate solution is measured after 5 minutes and recorded.
4.      The silver nitrate solution is poured quickly and carefully into the sodium chloride solution.
5.      The mixture is stirred with a thermometer throughout the experiment and the highest temperature obtained is recorded.
Result:


Mass, m
c
q
= (25 + 25) g = 50 g
4.2
Initial temperature of sodium chloride solution     = T1oC
Initial temperature of the silver nitrate            = T2 oC
Highest temperature reached                                            = T4 oC
=> Average initial temperature = (T1+T2)/2                       = T3 oC
è Increase in temperature,  q = (T4 - T3) oC



Calculation:


No of moles of sodium chloride used

No of moles of silver nitrate used
= MV/1000 = 0.0125 mole

= MV/1000= 0.0125 mole

Chemical equation: AgNO3 (aq) + NaCl (aq) à AgCl (s) + NaNO3 (aq)
Ionic equation:              Ag + (aq)                              +              Cl- (aq) à           AgCl (s)
                                                             1 mole                                  1 mole                  1 mole


Heat released =              mc
q
                                             =              (25 + 25 ) x 4.2 x (T4 - T3)
                                             =              x J
0.0125 mole of AgCl precipitated releases x J of heat energy.
Therefore, 1 mole of AgCl precipitated will released
Heat of precipitation, DH = x/0.0125 J = y J

Thermochemical equation:
AgNO3 (aq) + NaCl (aq) à AgCl (s) + NaNO3 (aq)                             DH = - y/1000 kJmol-1

Form 5 Chapter 4 Thermochemistry

Planning of experiment:


1

Different members of this homologous series have different heat of combustion. Table below shows the heat of combustion of some alcohols.





Alcohol
Alcohol
Heat if combustion (KJ mol-1)
Haba pembakaran (KJ mol-1)
Methanol
Metanol
- 728
Ethanol
Etanol
- 1376
Propan-1-ol
Propan-1-ol
-2016
Butan-1-ol
Butan-1-ol
- 2678







Plan a laboratory experiment to determine the heat of combustion of alcohols shown in the table.
Your planning should include the following aspects:








(a)                Statement of the problem
Pernyataan masalah

(b)              All the variables
Semua pembolehubah

(c)               Hypothesis
            Hipotesis

(d)              List of materials and apparatus
Senarai bahan dan radas

(e)               Procedure
            Prosedur

(f)                Tabulation of data
Penjadualan data
[17 marks]
[17 markah]


Suggested Answer:

Aim
To study the heat of combustion of different alcohols .
Problem statement
Do alcohols with more carbon atoms per molecule have higher value of heat of combustion?
Variables

MV: Different types of alcohol
RV: Heat of combustion
FV:   1. Volume of water        2. type of container/size of container
Hypothesis
Different type of alcohol produces different heat of combustion.
Apparatus & Materials
A: copper beaker, spirit lamp, thermometer, weighing balance, wooden block, tripod stand, wind shield, measuring cylinder.
M: Ethonol, propanol, butanol, water,
Procedure:

1. [200 cm3] of water is poured into a [copper] beaker.
2. Initial temperature of the water is recorded.
3. A spirit lamp is half filled with ethanol.
4. Initial mass of the spirit lamp is recorded.
5. Put the spirit lamp under the copper beaker and ignite the wick immediately.
6. Stir the water and the flame is put off after the temperature has increased by 30oC.
7. The highest temperature of the water is recorded.
8. Immediately the final mass of the spirit lamp is recorded.
9. Repeat the experiment by replacing ethanol with propanol and butanol.
Tabulation of data
Type of alcohol
Initial temperature / oC
Final temperature / oC
Initial mass of spirit lamp / g
Final mass of spirit lamp / g
Methanol




Ethanol




Propan-1-ol




Butan – 1- ol
